How to map a network drive on Windows 11 (GUI, CMD, GPO)
How to map a network drive on Windows 11 from File Explorer, net use, New-SmbMapping, a Group Policy Preferences Drive Map and an Intune platform script, how to find a mapped drive's full path and read a user's mappings from a remote session, why the letter is missing when the mapping worked, and the four SMB settings in 24H2 that refuse a connection.
Updated: November 2026
A new hire needs the finance share on day one, and the ticket says "the S drive is missing again." Mapping it by hand works for one PC, but the second time it breaks you want a method that survives sign-ins, policy refreshes and a Windows 11 upgrade. Here is how to map a network drive on Windows 11 from File Explorer, from the command line, from PowerShell and through Group Policy, plus the four settings in 24H2 that make a working mapping fail.
Map a network drive from File Explorer
The manual route is fine for one machine or a one-off share. Microsoft's own steps for Windows 10 and 11 are short.
- Open File Explorer, select This PC in the left pane, then select More (the three dots) on the toolbar and choose Map network drive. If the toolbar hides it, right-click This PC instead.
- Pick a letter from the Drive list. Letters near the end of the alphabet avoid clashes with USB sticks and card readers.
- In Folder, type the UNC path, such as
\\fs01\finance, or use Browse to find it. - Tick Reconnect at sign-in if the drive should come back after a restart. Tick Connect using different credentials if the share needs an account other than the one signed in.
- Select Finish.
If Browse shows nothing, network discovery is off. File Explorer's Network view shows a banner for that; select it and choose Turn on network discovery and file sharing. Typing the UNC path works without discovery, so skip the banner when you know the path.
To remove a mapping, right-click the drive under This PC and choose Disconnect.
Map a drive from the command line with net use
net use has mapped drives since Windows NT and still does the job in a Command Prompt or a logon script. The shape is drive letter, UNC path, then options.
cmdnet use S: \\fs01\finance /persistent:yes net use S: \\fs01\finance /user:CONTOSO\jdoe * /persistent:yes net use * \\fs01\finance net use S: /delete net use * /delete net use
Line by line: the first maps S: and saves it for the next sign-in. The second maps it with a different account and prompts for the password, because the * after the username asks rather than putting the password in the command history. The third takes the next free letter. The two /delete lines remove one mapping or all of them, and bare net use lists what is mapped right now, including drives that show a red X in File Explorer.
Two options need care. /persistent:yes applies to every mapping you make after it in that session, not just the one on the line, because Windows remembers the last setting used. And /savecred stores the credentials in Windows Credential Manager, which is convenient on a personal PC and a liability on a shared one, since anyone who signs in as that user gets the share without a prompt.
The thread above asks the question users ask technicians: is a mapped letter different from typing the path? Same share, same permissions. The letter is a shortcut stored for that user, plus a flag that says whether to rebuild it at sign-in.
Map a drive with PowerShell (new-PSDrive and New-SmbMapping)
PowerShell has two cmdlets that look alike and behave differently, and picking the wrong one is the most common reason a scripted mapping never appears in File Explorer.
powershell# A Windows mapped drive, visible in File Explorer and net use New-PSDrive -Name "S" -PSProvider FileSystem -Root "\\fs01\finance" -Persist -Scope Global # The same thing through the SMB module New-SmbMapping -LocalPath "S:" -RemotePath "\\fs01\finance" -Persistent $true # Check what is mapped, then remove one Get-SmbMapping Remove-SmbMapping -LocalPath "S:" -Force
Without -Persist, New-PSDrive creates a temporary PowerShell drive. It works inside that session and vanishes when the window closes. File Explorer, net use and other apps never see it, because, as Microsoft's cmdlet reference puts it, temporary drives are known only to PowerShell.
-Persist turns it into a Windows mapped drive, with three conditions: the name must be a single letter, the provider must be FileSystem, and the root must be a UNC path. Add -Scope Global when the command runs inside a script, or the drive disappears when the script's scope ends, which looks exactly like a mapping that silently failed.
New-SmbMapping skips those traps. It always creates a real Windows mapping and takes -Persistent $true for sign-in survival. It sits well next to the other useful PowerShell commands a technician keeps to hand.
Map drives for a whole office with Group Policy
For domain-joined PCs, Group Policy Preferences Drive Maps is the method that scales: it applies at sign-in, repairs itself at every refresh, and needs no script.
In the Group Policy Management Console, edit a GPO linked to the users' OU and go to User Configuration, Preferences, Windows Settings, Drive Maps. Create a new mapped drive and fill in four things: the Location as a UNC path, the Drive Letter, a Label as name users will see, and Reconnect ticked so the mapping is saved in the user's profile. The Action field decides how the item behaves.
Use Update for almost everything. It creates the mapping if it is missing and otherwise changes only the settings in the item, so a user with a file open does not lose the drive during a refresh. Replace deletes and recreates the drive every time policy applies, which is the cause behind "my S drive disappears for a second every ninety minutes."
Item-level targeting, on the Common tab, scopes one item to a security group, an OU or an IP range. One GPO maps the finance share for the finance group and the projects share for everyone.
Do not type credentials into the Connect as fields. Since the MS14-025 update in May 2014, the Group Policy editor no longer lets you save a password in a Drive Map item, because the stored value could be decrypted by any domain user. If a share needs a different account, fix the permissions on the share instead.
When a Drive Map item can't express the logic, for example a share path built from the user's department attribute, a logon script still works. Put a .bat with net use lines, or a .ps1 with New-SmbMapping, under User Configuration, Policies, Windows Settings, Scripts (Logon/Logoff). The script runs at every sign-in, so add a check for an existing mapping or delete the letter first. Drive Maps are still the better default, because they reapply at background refresh and a script doesn't.
Map drives on Intune and Entra-joined PCs
Intune has no Drive Maps equivalent, so a cloud-only fleet needs a script. The usual route is a platform script: in the Intune admin center, go to Devices, Scripts and remediations, Platform scripts, Add, Windows 10 and later.
powershell# Intune platform script. Set "Run this script using the logged on credentials" to Yes if (-not (Get-SmbMapping -LocalPath "S:" -ErrorAction SilentlyContinue)) { New-SmbMapping -LocalPath "S:" -RemotePath "\\fs01\finance" -Persistent $true }
Three settings decide whether it works. Run this script using the logged on credentials must be Yes, because a mapping made in the system context belongs to nobody who signs in. Enforce script signature check defaults to Yes, so an unsigned script fails until you sign it or switch that off. And assign the script to a user group, so each user gets their own mapping.
Microsoft's documentation adds the catch. Once a platform script runs, it doesn't run again unless the script or the policy changes. A user who deletes S: keeps it deleted. That's why the -Persistent $true matters, and why fleets that need self-repair schedule the same check as a Remediation, which needs Windows Enterprise or Education licensing.
The PC still has to reach the file server on port 445, on site or over VPN. And for single sign-on from an Entra-joined PC to an on-premises share, the user needs a hybrid identity synced from Active Directory.
Find a mapped drive's full path and registry key
File Explorer shows the letter and a label, not the path behind it. Three commands show the UNC path for every mapping the current user has.
powershellnet use # every mapping, including disconnected ones Get-SmbMapping # LocalPath, RemotePath and Status (Get-PSDrive S).DisplayRoot # the path behind one letter
Persistent mappings live in the user's registry hive, under HKEY_CURRENT_USER\Network\<letter>, and the RemotePath value holds the UNC path. Because the key sits in each user's own hive, a normal mapping belongs to one user. On a domain, "map a drive for all users" means a Drive Map item or a logon script that applies to everyone who signs in.
Windows does have a machine-wide option, New-SmbGlobalMapping, which lets every user, app and container on the PC use one mapping. Microsoft built it for Windows containers, and it has trade-offs on a shared desktop: it needs a stored credential, everyone reaches the share as that one account, and it doesn't support DFS Namespace folder shares. Keep it for container hosts and single-purpose machines.
To remap a letter to a new server, delete it and map it again: net use S: /delete, then net use S: \\fs02\finance /persistent:yes. A Drive Map item set to Update does the same at the next refresh once you change its Location.
Check a user's drives from a remote session
When a support tool runs a script as SYSTEM, net use and Get-SmbMapping report SYSTEM's own mappings. They come back empty, and the user's S: drive looks missing when it isn't. Read each signed-in user's hive instead:
powershell# Run as SYSTEM: persistent mapped drives for every signed-in user foreach ($hive in Get-ChildItem Registry::HKEY_USERS) { $net = "Registry::$($hive.Name)\Network" if (Test-Path $net) { $user = try { (New-Object System.Security.Principal.SecurityIdentifier $hive.PSChildName).Translate([System.Security.Principal.NTAccount]).Value } catch { $hive.PSChildName } Get-ChildItem $net | ForEach-Object { [pscustomobject]@{ User = $user; Drive = $_.PSChildName; Path = (Get-ItemProperty $_.PSPath).RemotePath } } } }
HKEY_USERS holds a user's hive while they're signed in, and only drives mapped with Reconnect at sign-in or /persistent:yes are written there. OpenFrame can run this script across a client's devices and collect the output, so a "the S drive is missing again" ticket starts with the path each user had.
Why the drive does not show up
The mapping "worked" but the letter is missing from File Explorer. Four causes cover nearly every ticket.
You mapped it as an administrator. With User Account Control on, an admin account gets two sign-in sessions, a standard one and an elevated one, and a drive mapping belongs to the session that created it. Map a drive from an elevated PowerShell and the standard File Explorer session never sees it; the reverse is why a mapped drive vanishes inside an app you ran as administrator. Microsoft documents the EnableLinkedConnections registry value as a workaround, but the cleaner fix is to test mappings as the user who will use them.
The poster above tried a GPO Drive Map, a scheduled task and a logon script, and the drive never appeared. The resolution was the first cause on this list: they were testing as a domain admin, and on a standard user account every method worked. The replies also caught the second cause, New-PSDrive where New-SmbMapping was wanted.
The script used a temporary PowerShell drive. Covered above: no -Persist, no -Scope Global, no drive after the script exits.
The policy item uses Replace. The drive exists, then disappears during the refresh, then returns. Switch the action to Update.
The drive reconnects before the network is ready. Laptops on Wi-Fi sign in before the adapter has an address, so the saved mapping fails with "Could not reconnect all network drives" and opens the moment the user clicks it. On a domain the policy Always wait for the network at computer startup and logon makes sign-in wait; on a workgroup PC a scheduled task that runs net use at logon with a short delay does the same job.
Four settings that break mappings on Windows 11 24H2
Windows 11 tightened SMB in ways that turn an old NAS or a router share into an error. The mapping command is right; the connection is refused. These are the four to check, with the error each produces.
SMB1 is gone. Windows 11 ships without the SMB1 client or server. A device that only speaks SMB1 produces "You can't connect to the file share because it's not secure" or "The specified network name is no longer available." Microsoft's advice is to update or replace the device rather than reinstall SMB1; Get-WindowsOptionalFeature -Online -FeatureName SMB1Protocol shows whether it is present.
Signing is required. Windows 11 24H2 Pro, Enterprise and Education require SMB signing in both directions by default. A third-party server that cannot sign fails with 0xc000a000, "The cryptographic signature is invalid." Microsoft says to enable signing on the server, not to turn the requirement off on the client. Get-SmbClientConfiguration | FL RequireSecuritySignature shows the client's state.
Guest access is blocked. Shares that allow anyone in without a password fail with "You can't access this shared folder because your organization's security policies block unauthenticated guest access." Guest logons do not support signing, so on 24H2 the two settings compound. Give the share a real account instead.
Name resolution or the firewall. Error 0x80070035, "The network path was not found," means the client could not reach port 445 on the server by that name. Check the name first with nslookup fs01, because a stale record or a DNS server not responding produces the same message. Then check the server's firewall for the File and Printer Sharing (SMB-In) rule. Mapping by IP address, such as \\10.0.0.5\finance, skips DNS and proves the path works, but Kerberos needs a name, so Windows falls back to NTLM. Use it as a test, not as the fix.
A red X on a working drive is a different thing: the server drops idle SMB sessions after 15 minutes by default, and the drive reconnects the moment it is clicked.
Which method to use
One PC, one share: File Explorer with Reconnect at sign-in ticked. A workgroup or a handful of PCs: a logon script with net use or New-SmbMapping. A domain: a Group Policy Drive Map with the Update action and item-level targeting by group. An Entra-joined fleet: an Intune platform script with New-SmbMapping, run with the user's credentials. A share that needs a different account than the user's own: fix the share permissions, because every method that stores a password for you is the one you will regret.
Short version
Map it in File Explorer for one PC, with net use or New-SmbMapping for a script, and with a Group Policy Drive Map set to Update for a domain. When the letter is missing, check whether you mapped it from an elevated session. When the connection is refused on Windows 11 24H2, check SMB1, signing and guest access on the server before touching the client. If the path itself will not resolve, start with the ipconfig commands that show which DNS server the PC is asking.
